◆Laser Modulation: Analog Modulation or TTL Modulation
◆Laser Type: Pure Solid-State Laser, High Stability, Long Lifespan.
◆Laser Beam Size at Output Port: <9×6mm
◆Laser Beam Divergence Angle: <1.3mrad
◆Laser Wavelength: Red 638±5nm, Green 520±5nm, Blue 450±5nm
◆Scanning system: 30KPPS high-speed galvanometer
◆Galvanometer scanning angle: ±30°; input signal ±5V; linear distortion <2%
◆Control mode: Ethernet ILDA computer laser software/DMX512/standalone/master-slave/optional mobile Bluetooth app
◆Control channels: 16CH/20CH
◆Safety and intelligence: Automatic shutdown when no signal is detected; DMX signal and PC signal can be switched. Features a single-beam protection function: if the galvanometer malfunctions and only one beam is emitted, the system will automatically shut down.
◆Suitable venues: Small to medium-sized performances, bars, etc.
◆Operating environment: Indoor
◆Cooling system: Forced air cooling with built-in fan
◆Product dimensions/net weight: 31 x 24 x 21 cm/6 kg
◆Carton dimensions/gross weight: 44 x 32 x 27 cm/11 kg
◆Outer carton dimensions for two units: 44 x 34 x 58 cm/23 kg
